Pro-Jay 125mm Mustang Style Low Profile Throttle Bodies

Pro-Jay MTB was specially designed for extreme high boost application. By removing unwanted features and spending special detail in durability and performance, we have achieved perfect form and function.

Features;
- Square pattern
- Billet Aluminum 6061-T
- 100% Stainless Steel Hardware
- 1/8 Thick Brass Butterfly with Double Knife edge
- Double Large O-ring on V-flange and on Bolting Flange
- Adjustable linkage with an Oversized 7/16 Stainless Steel Shaft
- Over size bushing for extra shaft support and double viton o-ring per side
- 2-3/4" long including Body, Ring and Clamp
- No EGR valve port to Block
- No Vacuum port to block
- Weld in v-band ring and v-band clamp included
- 2 Large O-ring front and back included

Using 1986-1993 Ford Mustang TPS ( Not Included )

80mm - Standard Bolt Pattern
3.470" x 3.470"
90mm - Standard Bolt Pattern
3.470" x 3.470"
100mm - Oversize Bolt Pattern
4.125" x 4.125"
105mm - Oversize Bolt Pattern
4.125" x 4.125"
115mm - Oversize Bolt Pattern
4.500" X 4.500" and 5.000" x 5.000"
125mm - Oversize Bolt Pattern
4.500" X 4.500" and 5.000" x 5.000"


Please call before ordering
Porfavor de llamar ante de poner una orden
1-856-297-8234
